Description

Essentials

• Product Collection,10th Generation Intel® Core™ i5 Processors
• Code Name,Products formerly Comet Lake
• Vertical Segment,Desktop
• Processor Number,i5-10400
• Lithography,14 nm

CPU Specifications

• Total Cores,6
• Total Threads,12
• Max Turbo Frequency,4.30 GHz
• Intel® Turbo Boost Technology 2.0 Frequency‡,4.30 GHz
• Processor Base Frequency,2.90 GHz
• Cache,12 MB Intel® Smart Cache
• Bus Speed,8 GT/s
• TDP,65 W

Supplemental Information

• Marketing Status,Launched
• Launch Date,Q2'20
• Embedded Options Available,No
• Use Conditions,PC/Client/Tablet
• Datasheet,View now

Memory Specifications

• Max Memory Size (dependent on memory type),128 GB
• Memory Types,DDR4-2666
• Max # of Memory Channels,2
• Max Memory Bandwidth,41.6 GB/s
• ECC Memory Supported   ‡,No

GPU Specifications

• GPU Name‡,Intel® UHD Graphics 630
• Graphics Base Frequency,350 MHz
• Graphics Max Dynamic Frequency,1.10 GHz
• Graphics Video Max Memory,64 GB
• 4K Support,Yes |  at 60Hz
• Max Resolution (HDMI)‡,4096 x 2160@30Hz
• Max Resolution (DP)‡,4096 x 2304@60Hz
• Max Resolution (eDP - Integrated Flat Panel)‡,4096 x 2304@60Hz
• DirectX* Support,12
• OpenGL* Support,4.5
• Intel® Quick Sync Video,Yes
• Intel® InTru™ 3D Technology,Yes
• Intel® Clear Video HD Technology,Yes
• Intel® Clear Video Technology,Yes
• # of Displays Supported ‡,3
• Device ID,0x9BC8 / 0x9BC5

Expansion Options

• Scalability,1S Only
• PCI Express Revision,3.0
• PCI Express Configurations ‡,Up to 1x16 |  2x8 |  1x8+2x4
• Max # of PCI Express Lanes,16

Package Specifications

• Sockets Supported,FCLGA1200
• Max CPU Configuration,1
• Thermal Solution Specification,PCG 2015C
• TJUNCTION,100°C
• Package Size,37.5mm x 37.5mm

Advanced Technologies

• Intel® Optane™ Memory Supported ‡,Yes
• Intel® Thermal Velocity Boost,No
• Intel® Turbo Boost Max Technology 3.0 ‡,No
• Intel® Turbo Boost Technology ‡,2.0
• Intel® Hyper-Threading Technology ‡,Yes
• Intel® Transactional Synchronization Extensions,No
• Intel® 64 ‡,Yes
• Instruction Set,64-bit
• Instruction Set Extensions,Intel® SSE4.1 |  Intel® SSE4.2 |  Intel® AVX2
• Idle States,Yes
• Enhanced Intel SpeedStep® Technology,Yes
• Thermal Monitoring Technologies,Yes
• Intel® Identity Protection Technology ‡,Yes

Security & Reliability

• Intel® Software Guard Extensions (Intel® SGX),Yes with Intel® ME
• Intel® AES New Instructions,Yes
• Secure Key,Yes
• Intel® OS Guard,Yes
• Intel® Trusted Execution Technology ‡,No
• Execute Disable Bit ‡,Yes
• Intel® Boot Guard,Yes
• Intel® Stable IT Platform Program (SIPP),No
• Intel® Virtualization Technology (VT-x) ‡,Yes
• Intel® Virtualization Technology for Directed I/O (VT-d) ‡,Yes
• Intel® VT-x with Extended Page Tables (EPT) ‡,Yes
