Description

CPU

• AMD Socket FM2+ Athlon/A- Series processors
• Supports CPU up to 4 cores
• Supports AMD Turbo Core 3.0 technology

Chipset

• AMD A68H FCH (Bolton D2H)

Memory

• 2 x DIMM, Maximum 32 GB DDR3
• 2400(O.C.)/2133(O.C.)/1866(O.C.)/1600(O.C.)/1333(O.C.) MHz
• Non-ECC, Un-buffered Memory
• Dual channel memory architecture
• Support AMD Memory Profile (AMP) memory
• Note: The maximum 32GB memory capacity can be supported with DIMMs of 16GB (or above). ASUS will update QVL once the DIMMs are available on the market
• Hyper DIMM support is subject to the physical characteristics of individual CPUs
• Due to OS limitations, when installing total memory of 4 GB capacity or more, Windows 32-bit operation system may only recognize less than 3GB. Install a 64-bit Windows OS when you want to install 4GB or more memory on the motherboard

Graphics

• Integrated AMD Radeon R/HD8000/HD7000 Series Graphics in the A-Series APU
• Multi-VGA Output Support: HDMI/DVI/RGB ports
• - Supports DVI with maximum resolution 2560 x 1600 at 60 Hz
• - Supports RGB with maximum resolution 1920 x 1600 at 60 Hz Maximum shared memory of 2048 MB AMD Dual Graphics technology support *

Expansion Slots

• 1 x PCIe 3.0/2.0 x16 *
• 1 x PCIe 2.0 x1
• 1 x PCI

Storage

• AMD A68H FCH (Bolton D2H) Chipset:
• 4 x SATA 6 Gb/s ports, gray
• Support RAID 0, 1, 10, JBOD

LAN

• Realtek 8111GR
• 1 x Gigabit LAN controller

Audio

• Realtek ALC887-VD 8-Channel High Definition Audio CODEC *
• - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
• Audio Feature:
• - LED-lit audio shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference, with a gorgeous illuminated trace path
• - Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals
• - Premium Japanese-made audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity

USB Ports

• AMD A68H FCH (Bolton D2H) Chipset:
• 6 x USB 2.0/1.1 ports (2 at back panel, 4 at mid-board)
• AMD A68H FCH (Bolton D2H) Chipset:
• 2 x USB 3.0 ports (2 at mid-board)

Special Features

• ASUS 5X Protection:
• - ASUS DIGI+ VRM - 3 + 2 Phase digital power design
• - ASUS Enhanced DRAM overcurrent protection - Short circuit damage prevention
• - ASUS ESD Guards - Enhanced ESD protection
• - ASUS High-Quality 5K-Hour Solid Capacitors - 2.5x long lifespan with excellent durability
• - ASUS Stainless Steel Back I/O - 3x more durable corrosion-resistant coating
• ASUS EPU:
• - EPU
• ASUS Exclusive Features:
• - AI Suite 3
• - Ai Charger+
• - Anti-Surge
• - ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface
• - USB 3.0 Boost
• - Disk Unlocker
• ASUS Quiet Thermal Solution:
• - Stylish fanless design heat-sink solution
• - ASUS Fan Xpert
• ASUS EZ DIY:
• - ASUS CrashFree BIOS 3
• - ASUS EZ Flash 2
• - ASUS MyLogo 2
• - Push Notice
• ASUS Q-Design:
• - ASUS Q-Slot

Back I/O Ports

• 1 x PS/2 keyboard (purple)
• 1 x PS/2 mouse (green)
• 1 x DVI
• 1 x D-Sub
• 1 x HDMI
• 1 x LAN (RJ-45) port
• 2 x USB 3.0
• 2 x USB 2.0
• 3 x Audio jacks

Internal I/O Ports

• 2 x USB 2.0 connector support additional 4 USB 2.0 ports
• 1 x TPM connector
• 1 x COM port connector
• 4 x SATA 6 Gb/s connectors
• 1 x CPU Fan connector
• 1 x Chassis Fan connector
• 1 x S/PDIF out header
• 1 x 24-pin EATX Power connector
• 1 x 4-pin ATX 12 V Power connector
• 1 x Front panel audio connector (AAFP)
• 1 x Internal speaker connector
• 1 x System panel

BIOS

• 64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.7, ACPI 4.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS 3, My Favorites, Quick Note, Last modified log, F12 PrintScreen, F3 Shortcut functions and ASUS DRAM SPD (Serial Presence Detect) memory information.

Support Disc

• Drivers
• ASUS utilities
• ASUS update
• Anti-virus software (OEM version)

Compatible Operating Systems

• Windows 8.1, 32/64-bit
• Windows 8, 32/64-bit
• Windows 7, 32/64-bit
• Windows XP, 32-bit

Form Factor

• mATX

Dimensions

• 8.9 x 7.0" (22.6 x 18.0 cm)
