Description

WIRELESS

Standards

Wi-Fi 4: IEEE 802.11n/b/g 2.4 GHz

WiFi Speeds

N300: 2.4 GHz: 300 Mbps (802.11n)

WiFi Range

4 Bedroom Houses

2× Detachable 9 dBi High-Gain Antennas

Multiple antennas form a signal-boosting array to cover more directions and large areas

High-Power FEM

Improves transmission power to strengthen signal coverage

WiFi Capacity

Legacy

Working Modes

Router Mode

Access Point Mode

Range Extender Mode

HARDWARE

Processor

Single-Core CPU

Ethernet Ports

1× 10/100 Mbps WAN Port

4× 10/100 Mbps LAN Ports

Buttons

Wi-Fi On/Off Button

Power On/Off Button

WPS Button

Reset Button

Power

12 V ⎓ 1 A

SECURITY

WiFi Encryption WEP

WPA

WPA2

WPA/WPA2-Enterprise (802.1x)

Network Security

SPI Firewall

Access Control

IP & MAC Binding

Application Layer Gateway

Guest Network

1× 2.4 GHz Guest Network

SOFTWARE

Protocols

IPv4

IPv6

Parental Controls

URL Filtering

Time Controls

WAN Types

Dynamic IP

Static IP

PPPoE

PPTP

L2TP

Quality of Service

QoS by Device

NAT Forwarding

Virtual Server

Port Forwarding

Port Triggering

DMZ

UPnP

IPTV

IGMP Proxy

IGMP Snooping

DHCP

Address Reservation

DHCP Client List

Server

DDNS

NO-IP

DynDNS

Management

Tether App

Webpage

OTHER

System Requirements

Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser

Cable or DSL Modem (if needed)

Subscription with an internet service provider (for internet access)

Certifications

FCC, CE, RoHS
